Turn Block™ Indexing Turntable

No code integration: Simplifies the setup and deployment process.

Control up to 8 stations with plug and play apps: Enables easy expansion and management of complex operations.

Select Program direction, speed, acceleration, deceleration, and # of positions: Provides precise control over operations.

Touch Screen 7” HMI and PLC with Ethernet IP, Modbus, digital I/O, 0-10V analogue communications: Offers an intuitive and efficient user interface.

Machine base expandable and reconfigurable with modular block structure: Provides flexibility for future modifications and upgrades.

Table Diameter: 24” (sold separately)

Standard Repeatability: 5 Arc Min backlash maximum

Optional Precision Repeatability: 3 Arc Min backlash maximum

Indexing Positions: 4 and 8

Max Table Speed: 20 RPM

Start/Stop Trigger Options: Remote, foot pedal, start/stop buttons, and timer.

Master Configuration: Coordinates with other machine blocks via a hierarchical handshake. Indexing starts with a trigger and proceeds only if all processes and operator actions are complete.

Auto Indexing Mode: Automatically indexes based on a programmable timer, subject to the same handshake. If the operator falls behind, the machine reverts to manual trigger mode.

Light Curtain Integration: Pauses indexing when the light curtain is broken; resumes when unbroken.

Part Presence Sensing: Detects unloaded/loaded parts with a programmable distance trigger. Ensures proper load/unload cycle before allowing table rotation. Skips process steps for empty nests.

Robot Block Integration: Robot waypoints, fault modes, local sensors, and EOAT triggers are programmed on the robot. Errors are reported to the Turn Block controller, displayed on the HMI, and indicated on the light tower.
